Capacity
Lifting Capacity*
10,000 lbs. (4,536 kg)
*Max Capacity / Front Axle
5,000 lbs. (2,268 kg)
*Max Capacity / Rear Axle
5,000 lbs. (2,268 kg)
Max Capacity per Lift Arm
2,500 lbs. (1,134 kg)
Dimensions
A – Width Overall :
139 in. (3,529 mm)
B – Base Plate Width:
25.25 in. (642 mm)
C – Post Height:
93.5 in. (2,377 mm)
D – Drive-Thru:
94 in. (2,389 mm)
E – Inside Posts:
111.25 in. (2,825 mm)
F – Outside Posts:
132.5 in. (3,365 mm)
G – Minimum Height w/ Pad:
4.75 in. (122 mm)
H – Maximum Lifting Height:
46.25 in. (1,185 mm)
I – Maximum Rise:
42.5 in. (1,081 mm)
J – Maximum Pad Adjustment:
2.25 in. (55 mm)
K – Floor Plate Height:
1.4 in. (36 mm)
L – Floor Plate Width:
9.5 in. (240 mm)
Arms & Pads
M – Front Arm Reach:
22.5 in. Min. – 47.5 in. Max. (562 mm Min. – 1,205 mm Max.)
N – Rear Arm Reach:
29.5 in. Min. – 57 in. Max. (747 mm Min. – 1,446 mm Max.)
Safety
Safety Lock Positions:
8 Positions positioned every 3.75 in. (95 mm)
Power Unit
Standard Motor:
208-240 VAC, 50/60 Hz, 1 Phase, Approx. 11 Amps
Hydraulic Fluid Required:
3.6 gallons (13.6 Liters)
Operating Hydraulic Pressure under Max. Load:
2,170 psi
Time to Full Rise:
≈45 seconds
Sound:
<43dB
Specifications
Capacity 10000
Design Two-Post
Type Heavy Duty
Configuration Symmetric
Configuration Asymmetric
Overall Height 93"
Overall Width 130"
Inside Columns 108"
