Lifting Capacity
9,000 lbs. (4,082 kg)
Max. Capacity / Front Axle
4,500 lbs. (2,045 kg)
Max. Capacity / Rear Axle
4,500 lbs. (2,045 kg)
A - Height Overall
109.5" (2,779 mm)
B - Width Overall (at Baseplate)
137.25" (3,486 mm)
C - Width Outside of Columns
127.5" (3,238 mm)
D - Floor To Driveover Height
1.25" (30 mm)
E - Width Inside Columns
113.25" (2,880 mm)
F - Front Arm Reach (Min.)
22.5" (571 mm)
F - Front Arm Reach (Max.)
43.25" (1,099 mm)
G - Rear Arm Reach (Min.)
33.25" (845 mm)
G - Rear Arm Reach (Max.)
53.50" (1,360 mm)
H - Min. Pad Height
4" (100 mm)
I - Rise
70" (1,780 mm)
J - Max. Lift Height (Pad + 63mm Adapt.)
76.5" - 78.5" (1,943 - 1,994 mm)
K - Drive-Thru Clearance
103" (2,618 mm)
Screw Pad Adjustment
2" (51 mm)
Motor
220 VAC / 60Hz / 1 Ph
Time of Full Rise
65 seconds
Max. Load Per Arm
2,250 lbs. (1,023 kg)
Shipping Weight
1,385 lbs. (630 kg)
Specifications
Capacity 9000
Design Two-Post
Configuration Asymmetric
Type Low Ceiling
Color Black
Overall Height 109.5"
Overall Width 137.25"
Inside Columns 113.25
Country of Origin Asia
