Lifting Capacity
20,000 lbs. / 9,072 kg
A - Max. Rise (no Safety Lock engaged) 1
76.5 in. (1,943 mm)
B1 - Max. Lifting Height w/ Pad (Top Lock) 2
82.75 in. (2,103 mm)
B2 - Max. Lifting Height w/Pad (no Lock) 3
83.25 in. (2,114 mm)
C - Max. Lifting Height w/Adapters (Top Lock) 4
90.25 in. (2,292 mm)
D - Min. Height w/ Pad
8 in. (206 mm)
E - Overall Height
169 in. (4,294 mm)
F - Width Overall
168 in. (4,267 mm)
G - Outside Posts
149 in. (3,785 mm)
H - Inside Posts
126 in. (3,199 mm)
I - Drive-Thru Width
107.75 in. (2,742 mm)
J - Floor to Top Switch
162.5 in.(4,128 mm)
K - Lift Arm Reach (min. - max.)
35 in. to 62 in. (893 mm to 1,678 mm)
L - Base Plate Width
28 in. (710 mm)
M - Post to Base Plate
9.5 in. (241 mm)
Time to Full Rise
≈ 79 seconds
Operating Pressure at Maximum Load
2,647 psi
Specifications
Capacity 20,000
Design Two-Post
Type Heavy Duty
Overall Height 169''
Overall Width 168''
