Lifting Capacity
20,000 lbs. / 9,072 kg
Max. Capacity — Front Axle
10,000 lbs. / 4,536 kg
Max. Capacity — Rear Axle
10,000 lbs. / 4,536 kg
A - Max. Rise
76.25 in. / 1,934 mm
B - Lifting Height w/ Pad1
83 in. / 2,111 mm
C - Max. Lifting Height1
91.5 in. / 2,327 mm
D - Min. Height w/ Pad
8 in. / 206 mm
E - Height Overall
193 in. /
Â
4,904 mm
F - Width Overall
168 in. / 4,267 mm
G - Outside Posts
149 in. / 3,785 mm
H - Inside Posts
126 in. / 3,199 mm
I - Drive-Thru Width
107.75 in. / 2,739 mm
J - Floor to Top Switch
186.5 in. / 4,738 mm
K - Front Arm Reach
35 in. to 62 in. (893 mm to 1,678 mm)
K - Read Arm Reach
35 in. to 62 in. (893 mm to 1,678 mm)
L - Base Plate Width
28 in. / 710 mm
M - Post to Base Plate
9.5 in. / 241 mm
Max. load per Lift Arm
5,000 lbs. / 2,268 kg
Motor2
220 VAC, 60 Hz, 1 Phase
Sound
<70 dB
Specifications
Capacity 20000
Design Two-Post
Type Super-Duty
Overall Height 193''
Overall Width 168''
