Lifting capacity:
6,000 lbs. (2,724 kg)
Max lifting capacity front axle:
3,000 lbs. (1,361 kg)
Max lifting capacity rear axle:
3,000 lbs. (1,361 kg)
Max lifting height:
23" (584 mm)
Max lift height + 1.5" blocks:
24.5" (622 mm)
Max lift height + optional 3" blocks:
26" (661 mm)
Overall pad length:
53" (1,346 mm)
Overall width:
70.5" (1,791 mm)
Overall length:
81" (2,054 mm)
Lowered height:
4" (102 mm)
Lifting time:
35 seconds
Lift pad dimension:
18" x 52" (457 mm x 2,591 mm)
Motor:
110 VAC / 50-60 Hz / 1 Ph
Shipping weight:
974-lbs. (442 kg)
Shipping dimensions:
73'' x 84'' x 20'' (1,854 mm x 2,133 mm x 508 mm)
Specifications
Capacity 6000
Design Scissor
Type General Svc
