Lifting Capacity:
10,000 lbs. (4,545 kg)
Max Capacity / Front Axle:
5,000 lbs. (2,273 kg)
Max Capacity / Rear Axle:
5,000 lbs. (2,273 kg)
Lifting Height:
23" (581 mm)
Lifting Height + Blocks:
32” (810 mm)
1st. Lock Position:
14" (356 mm)
2nd. Lock Position:
18" (457 mm)
3rd. Lock Position:
20.75" (527 mm)
4th Lock Position:
22.75" (578 mm)
Overall Pad Length:
53” (1,346 mm)
Overall Length:
83.5" (2,124 mm)
Overall Pad Width:
24" (610 mm)
Overall Width:
85" (2,159 mm)
Lowered Height:
4.5" (113 mm)
Lifting Time:
35 seconds
Motor:
208-230VAC / 50-60Hz / 1 Ph
Shipping Weight
1,332-lbs. (604 kg)
Shipping Dimensions
88'' x 85'' x 24'' (2,235 mm x 2,159 mm x 609 mm)
Specifications
Capacity 10000
Design Scissor
Type General Svc
Application Alignment, Body Shop, Body Shops, Dealerships, Express Bays, Motorcycle, Residential, Tires & Brakes
Colors Black, Blue, Red
Country of Origin Asia, Italy
Height Full Rise, Low Rise, Mid Rise
Lift Accessory Efficiency, Finish, Ramp Kits
Lift Type Scissor
Mount Flush, Surface
Overall length 144”
Overall width 103”, 111”
Wheelbase 196'', 217''
