Lifting capacity:
7,000 lbs. (3,175 kg)
Max height raised:
70.5" (1,791 mm)
Single platform length:
62.5" (1,590 mm)
Single platform width:
22" (554 mm)
Overall length:
165" (4,190 mm)
Overall width - Min:
81.5" (2,068 mm)
Overall width - Max:
87.5" (2,218 mm)
Lowered lift height:
6.5" (165 mm)
Lifting time:
45 seconds
Motor:
208-240 VAC / 50-60 Hz / 1Ph
Shipping weight:
2,502-lbs. (1,134 kg)
Shipping dimensions:
106'' x 27'' x 43'' (2,692 mm x 685 mm x 1,092 mm)
Specifications
Capacity 7000
Design Scissor
Type General Svc
