Lifting capacity:
6,000 lbs. (2,724 kg)
Max lifting capacity front axle:
3,000 lbs. (1,361 kg)
Max lifting capacity rear axle:
3,000 lbs. (1,361 kg)
Max lifting height:
23" (584 mm)
Max lift height + 1.5" blocks:
24.5" (622 mm)
Max lift height + optional 3" blocks:
26" (661 mm)
Overall pad length:
53" (1,346 mm)
Overall width:
69.5" (1,764 mm)
Overall length:
81" (2,054 mm)
Lowered height:
3.5" (89 mm)
Lifting time:
35 seconds
Motor:
110 VAC / 50-60 Hz / 1 Ph
Lift pad dimension:
18" x 52" (457 mm x 1,320 mm)
Shipping weight:
940 lbs. (426 kg)
Shipping dimensions:
73" x 83" x 21" (1,854 mm x 2,108 mm x 533 mm)
Specifications
Capacity 6000
Design Scissor
Type General Svc
