Capacity
Lifting Capacity
12,000 lbs. (5,443 kg)
Max Capacity / Front Axle
6,000 lbs. (2,722 kg)
Max Capacity / Rear Axle
6,000 lbs. (2,722 kg)
Maximum Capacity per Lift Arm
3,000 lbs. (1,371 kg)
Dimensions
A – Width Overall:
155 in. (3,937 mm)
B – Base Plate Width:
26.5 in. (674 mm)
C – Post Height:
144.75 in. (3,676 mm)
D – Drive-Thru:
102.25 in. (2,599 mm)
E – Inside Posts:
119.125 in. (3,026 mm)
F – Outside Posts:
142.25 in. (3,612 mm)
G – Minimum Height with Pad:
4.5 in. (114 mm)
H – Max. Lifting Height:
73.5 in. (1,867 mm)
I – Max. Rise:
70 in. (1,775 mm)
J – Maximum Pad Adjustment:
2.25 in. (55 mm)
K – Floor Plate Height:
1.5 in. (36 mm)
L – Floor Plate Width:
9.5 in. (240 mm)
Arms & Pads
M – Asymmetric Arm Reach:
26 - 55.25 in. (660 - 1,404 mm)
N – Symmetric Arm Reach:
29.5 - 60 in. (745 - 1,525 mm)
Safety
Safety Lock Positions:
15 (Spaced Every 4" / 99 mm)
Power Unit
Standard Motor:
208-230 VAC, 50/60 Hz, 1 Phase, 5 HP, 23 Amps
Time to Full Rise:
≈68 seconds
Sound Pressure:
Lift produces less than 85dB when in operation.
Operating Hydraulic Pressure under Max. Load:
2,170 psi
Specifications
Capacity 12000
Style Floorplate
Type 2- Post Lift
