Model
PL-12000DPS
Number of Platforms
2
Load Capacity per Platform
6,000lbs / 2,722 kg
Total Width
221.5" / 5,620 mm
Outside Length
174" / 4,418 mm
Total Length
218.5" / 5,550 mm
Total Height
118.5" / 3,009 mm
Runway Height
5.00" / 127 mm
Maximum Rise
70.2" / 1,784 mm
Width Between Posts
211" / 5,362 mm
Width Between Short & Double Posts
100.25" / 2,546 mm
Width Between Platforms
29" / 739 mm
Width Between Runways
35" or 41" / 887 or 1,045 mm
Runway Length
159" / 4,039 mm
Runway Width
19" / 482 mm
Drive Thru Height
68.5" / 1,742 mm
Drive Thru Width
85" / 2,161 mm
Outside Edge of Runways
76 or 82" / 1,930 or 2,083 mm
Safety Lock Positions*
6
Lifting Time
≈45 Seconds
Power Unit / Motor**
220 VAC, 50/60 Hz, 1 Ph
Specifications
Capacity 12000
Design Four-Post
Type Parking
