Overall Height
131” (3,327.4mm)
Note: does not include the 2.5 in. / 57 mm Max. for Balance Chain Adj.
Note: does not include the 2.5 in. / 57 mm Max. for Balance Chain Adj.
Overall Length
163.5” (4,152.5 mm)
Overall Width
100.25” (2,547 mm)
Lifting Height
82.5” (2,100 mm)
Usable Platform Width
82.5” (2,100 mm)
Platform Length
157” (3,990 mm)
Electrical Required
110 or 220 VAC 50/60 Hz.
Single or Three Phase (specify when ordering)
Single or Three Phase (specify when ordering)
Control Power
24 VAC
Lock Release
Manual Release
Power Pack
2.2kw hydraulic power pump
Lifting / Lowering Time
50 / 45 sec.
Specifications
Capacity 6000
Design Two-Post
Type Parking
