Lifting Capacity per Platform
6,000 lbs. (2,700 kg)
A)Â Â Â Â Â Â Â Total Width, Outside Edge to Outside Edge
112 in. (2,847 mm)
B)Â Â Â Â Â Â Â Lift Platform Length
157 in. (3,990 mm)
C)Â Â Â Â Â Â Post Height, *See Note 1
131 in. (3,320 mm)
D)Â Â Â Â Â Â Post, Center to Center Width
105.5 in. (2,682 mm)
E)Â Â Â Â Â Â Â Â Post Support Length
60.25 in. (1,532 mm)
F)Â Â Â Â Â Â Â Â Lifting Height
82.5 in. (2,100 mm)
G)Â Â Â Â Â Â Control Column Height
71 in. (1,805 mm)
H)Â Â Â Â Â Â Lift Platform (Usable Width)
94.5 in. (2,400 mm)
I)Â Â Â Â Â Â Â Â Â Â Â Side Clearance Min.
2 in. (50.75 mm)
J)Â Â Â Â Â Â Â Â Â Â Platform to Support
36.25 in. (918.25 mm)
K)Â Â Â Â Â Â Â Â Length Overall
163.5 in. (4,152.5 mm
Lifting Time
<50 Seconds
Motor
208-240V, 50/60HZ, 1-Ph., 4 HP, 22 Amps
Operating Temperature and Humidity
+41° to +104°F / +5° to +40°C 50% RH
Specifications
Capacity 6000
Design Two-Post
Type Parking
