A - Overall Height (RAISED)
101” (2,565 mm)
B - Overall Height (LOWERED)
146.5” (3,721 mm)
C - Max. Lifting Height
71.5” (1,889 mm)
D - Overall Depth
48.75” (1,238 mm)
E - Overall Width
45” (1,143 mm)
F - Chassis Length
32.25” (819 mm)
G - Min. Lifting Fork Width
9.5” (241 mm)
H - Max. Lifting Fork Width
35” (889 mm)
I - Lifting Fork Length
11.5” (292 mm)
Turning Circle
40” (1,016 mm)
Column Weight
1,450 lbs. (657 kg)
Lifting Speed
85 sec
Shipping Weight
1,450 lbs. (657 kg)
Shipping Dimensions per Column
106'' x 55'' x 41'' (2,696 mm x 1,397 mm x 1,041 mm)
Specifications
Capacity 108,000
Design Scissor
Lift Accessory Efficiency
Lift Type Bridge Jack, Scissor
Style Extended
Type General Svc, Motocycle, Motorcycle Jack
