A - Min. Runway Height:
7" (178 mm)
B - Max. Rise:
70" (1,778 mm)
C - Max. Lifting Height:
77" (1,956 mm)
D - Overall Width:
202" (5,131 mm)
E - Outside Length:
174" (4,420 mm)
F - Overall Length:
218.5" (5,550 mm)
G - Height of Columns:
90" (2,284 mm)
H - Width Between Columns:
192" (4,877 mm)
I - Drive-Thru Clearance:
178" (4,521 mm)
J - Runway Width:
19" (483 mm)
K - Length of Runways:
164" (4,166 mm)
L - Width Between Runways:
34.25" (870 mm) - 41" (1,041 mm)
M - Runway Centerline:
56.25" (1,429 mm) - 62.75" (1,594 mm)
N - Outside Edge of Runways:
75.25" (1,911 mm) - 81.75" (2,076 mm)
Locking Positions:
14
Lock Spacing:
Every 4" (102 mm)
Time to Full Rise:
55 seconds
Motor:
220 VAC / 60 Hz / 1 Ph
Shipping Weight:
2,796 lbs. (1,268 kg)
Shipping Dimensions:
200” x 22” x 52” (5,080 mm x 5,080 mm x 1,333 mm)
Specifications
Capacity 9000
Design Four-Post
Type Parking
