Lifting Capacity
9,000 lbs. (4,082 kg)
A - Minimum Runway Height
5" (127 mm)
B - Maximum Rise
82" (2,083 mm)
C - Maximum Lifting Height
86.5" (2,197 mm)
Time to Full Rise
50 seconds
D - Width Overall
100.25" (2,546 mm)
E - Outside Length
198" (5,029 mm)
F - Overall Length
224" (5,690 mm)
G - Height of Columns
100" (2,540 mm)
H - Width Between Columns
89.75" (2,280 mm)
I - Drive-Thru Clearance
76.5" (1,943 mm)
J - Runway Width
19" (483 mm)
K - Length of Runways
188" (4,775 mm)
L - Width Between Runways
37.5" (953 mm)
M - Runway Centerline
56.5" (1,435 mm)
N - Outside Edge of Runways
75.5" (1,918 mm)
Rated Capacity
135" (3,429 mm)
75% Capacity
115" (2,921 mm)
50% Capacity
95" (2,413 mm)
25% Capacity
80" (2,032 mm)
Locking Positions
15
Lock Spacing
Every 4" (102 mm)
Shipping Dimensions
190" X 22" X 41"
Noise
45 dB
Specifications
Capacity 9000
Design Four-Post
Configuration Closed-Front
Type Parking
