Type:
Flush Mount
Lifting Capacity:
6,000 lbs. / 2,722 kg
Lifting Height (Full-Rise – No Blocks):
36.75 in. / 933 mm
Lifting Height (Full-Rise) Med. Lift Blocks (1.5 in. / 38mm):
38.25 in. / 972 mm
Lifting Height (Full-Rise) Tall Lift Blocks (2.9 in. / 75mm):
39.65 in. / 1,007 mm
Platform Length:
78.75 in. / 2,000 mm
Total Length:
78.75 in. / 2,000 mm (No ramps or extensions)
Lowered Height:
5.25 in. / 133 mm (Top of Platform to be Flush with floor)
Platform Width:
19 in. / 484 mm
Width Between Platforms:
40 to 46 in. / 1,018 to 1,168 mm
Ramp Length:
N/A (No Ramps)
Ramp Extension Length:
N/A (No Extensions)
Max. Platform to Console:
40 in. / 1,024 mm
Lifting Time:
35 seconds
Hydraulic Pressure Developed at Max. Capacity:
1700 psi / 11.72 N/m²
Motor:
110 VAC at 50-60 Hz., 1 Ph. / 220 VAC at 50 Hz., 1 Ph. / 208-230 VAC at 60 Hz., 1 Ph.
Specifications
Capacity 6000
Design Scissor
Type General Svc
