Specifications
Lifting Capacity
6,000 lbs. (2,721 kg)
Suitable Lift Model(s)
XR-12000 Series
Min. Drive-Over Height*
Pad Only:
1.25" (32 mm)
Pad + 2.75" Adapter:
4" (102 mm)
Pad + 5.5" Adapter:
6.75" (171 mm)
Max. Lifting Height*
Pad Only:
12" (305 mm)
Pad + 2.75" Adapter:
14.75" (375 mm)
Pad + 5.5" Adapter:
17.5" (445 mm)
Reach
Support Base Width:
36.25" (921 mm) - 47.25" (1,200 mm)
Max. Arm Reach:
56" (1,422 mm)
Min. Arm Reach:
42" (1,067 mm)
Time to Full Rise:
55 seconds
Pump:
Air/Hydraulic
Air Pressure:
125 PSI (10-25 CFM)
Max. Operating Hydraulic Pressure:
3,370 PSI
Power Requirement:
None
Shipping Weight:
436 lbs. (193 kg)
Shipping Dimensions:
42" x 24" x 14" (1,066 mm x 609 mm x 355 mm)
Specifications
Capacity 6000
