Lifting Capacity
25,000 lbs. (11,340 kg)
Suitable Lift Model(s)
HDS-40 Series
Min. Drive-Over Height*
Short Arm Pad:
9" (229 mm)
Short Top Pad:
9.75" (248 mm)
Tall Arm Pad:
10.5" (267 mm)
Tall Top Pad:
11.25" (286 mm)
Max. Lifting Height*
Short Arm Pad:
19" (483 mm)
Short Top Pad:
19.75" (502 mm)
Tall Arm Pad:
20.5" (521 mm)
Tall Top Pad:
21.25" (540 mm)
Reach
Support Base Width:
45" (1,143 mm)
Max. Arm Pad Reach:
63.75" (1,619 mm)
Min. Arm Pad Reach:
48.5" (1,232 mm)
Max. Top Pad Reach:
39.5" (1,003 mm)
Min. Top Pad Reach:
8" (203 mm)
Time to Full Rise:
55 seconds
Pump:
Air/Hydraulic
Air Pressure:
125 PSI (10-25 CFM)
Max. Operating Hydraulic Pressure:
7,200 PSI
Power Requirement:
None
Shipping Weight:
786 lbs. (356 kg)
Shipping Dimensions:
47" x 29" x 17" (1,206 mm x 736 mm x 431 mm)
Specifications
Capacity 25000
