Motor
3 HP (220 VAC 50-60 HZ)
Drive System Type
Electric / Air
Air Requirement
140-165 PSI (10-11 BAR)
Wheel Clamping Method
4 Clamps - Internal / External
Table Clamping System
Dual Pneumatic Cylinders
Bead Breaking System
Pneumatic Blade / Dual
Tower Design
Rigid / Fixed
Power Assist Towers
N/A
Bead Seating System
Turbo Blast / Bead Seating
A - Inside (Wheel) Clamping Range
10" - 30" (254 mm - 762 mm)
B - Outside (Wheel) Clamping Range
9" - 28" (229 mm - 762 mm)
Maximum Rim Width
15" (381 mm)
Maximum Tire Diameter
50" (1,270 mm)
Shipping Weight
742 lbs. (337 kg)
Shipping Dimensions
45" x 50" x 68" (1,143 mm x 1,270 mm x 1,727 mm)
Recommended Footprint
55" x 50" x 78" (1,397 mm x 1,270 mm x 1,981 mm)
Specifications
Power 208-240V
Type Tire Changer
Phase 1-Ph
Frequency 50/60hz
