Motor
3 HP (220 VAC 50-60 HZ)
Drive System Type
Electric / Air
Air Requirement
140 – 165 PSI (9.6-11.4 BAR)
Wheel Clamping Method
4 Clamps - Internal / External
Table Clamping System
Dual Pneumatic Cylinders
Bead Breaking System
Pneumatic Blade
Tower Design
Tilt-Back
Power Assist Towers
Dual / Left & Right
Bead Seating System
Turbo Blast / Bead Seating
A - Inside (Wheel) Clamping Range
13" - 34" (305 mm - 864 mm)
B - Outside (Wheel) Clamping Range
10" - 30" (254 mm - 762 mm)
Maximum Rim Width
15" (381 mm)
Maximum Tire Diameter
47" (1,194 mm)
Shipping Weight
1,256 lbs. (570 kg)
Shipping Dimensions
65'' x 60'' x 72'' (1,651 mm x 1,524 mm x 1,829 mm)
Recommended Footprint
72" x 70" x 76" (1,829 mm x 1,778 mm x 1,930 mm)
Specifications
Power 208-240V
Type Tire Changer
Style Tilt Back
Style Dual-Tower
Phase 1-Ph
Frequency 50/60hz
