Motor
3 HP (220 VAC 50-60 HZ)
Drive System Type
Electric / Hydraulic
Air Requirement
110-175 PSI (8-12 BAR)
Wheel Clamping Method
4 Clamps - Internal / External
Table Clamping System
Dual Pneumatic Cylinders
Bead Breaking System
Adjustable Pneumatic Blade
Tower Design
Tilt-Back
Power Assist Tower(s)
Single / Right-Side
Bead Lifting Roller(s)
Single / Right-Side
Upper Bead Assist Roller
Single / Right-Side
Vertical Shaft / Tool Head
Pneumatic / Locking
Powerful Bead Seating System
TurboBlast™
A - Inside (Wheel) Clamping Range
10" - 30" (254 mm - 762 mm)
B - Outside (Wheel) Clamping Range
9" - 28" (229 mm - 712 mm)
Maximum Rim Width
15" (381 mm)
Maximum Tire Diameter
43" (1,092 mm)
Shipping Weight
920 lbs. (417 kg)
Shipping Dimensions
50" x 50" x 68" (1,270 mm x 1,270 mm x 1,727 mm)
Recommended Footprint
60" x 50" x 78" (1,524 mm x 1,270 mm x 1,981 mm)
Specifications
Power 208-240V
Type Tire Changer
Style Tilt Back
Style Single-Tower
Phase 1-Ph
Frequency 50/60hz
