Motor
1.5 HP, 110V / 220V, 50 / 60 Hz, 1Ph
Cycle Time
6 - 9 Seconds (avg.)
Balancing Modes
Dynamic / Static / 3-Alloy
Drive System
Belt Drive
Wheel Braking
Automatic / Electronic
Collets Included
3 Standard / 1 Truck
Max. Tire Diameter
47" (1,194 mm)
Max. Tire Weight
145 lbs. (65 kg)
Wheel Diameter Capacity
10" - 30" (254 mm - 762 mm)
Wheel Width Capacity
1.5" - 18" (38 mm - 457 mm)
Balancing Increments
0.25 or 0.01 oz
Balancing Speed
180 RPM
Accuracy
+/- 1 gram (.035 oz)
Resolution
0.01 ounce, 1.4°
Shipping Weight
356 lbs. (161 kg)
Shipping Dimension
38" x 30" x 46" (965 mm x 762 mm x 1,168 mm)
Specifications
Power 110-240V
Type Wheel Balancer
Phase 1-Ph
Frequency 50/60hz
