Lifting capacity:
9,000 lbs. (4,082 kg)
Lifting Height:
23.75” (604 mm)
Lifting Height + Block:
27” (685 mm)
Overall Lift Platform Length:
58.5” (1,484 mm)
Overall Lift Platform Width:
24” (610 mm)
Overall Length:
124.6” (3,165 mm)
Lowered Height:
4" (102 mm)
Speed of rise:
55 seconds
Standard motor (*):
1.5 HP / 208-230 VAC / 60 Hz / 1 Ph
Shipping weight:
1,502-lbs. (681 kg)
Shipping dimensions:
77'' x 60'' x 24'' (1,966 cm x 1,534 mm x 609 mm)
Specifications
Capacity 9000
Design Scissor
Type General Svc
