Capacity
Lifting Capacity*
14,000 lbs. (6,350 kg)
*Max Capacity / Front Axle
7,000 lbs. (3,175 kg)
*Max Capacity / Rear Axle
7,000 lbs. (3,175 kg)
Rise
A - Min. Runway Height:
7.5" (191 mm)
B - Max. Rise:
82.75" (2,104mm)
C - Max. Lifting Height:
89.5" (2,275mm)
Time to Full Rise:
90 seconds
Outside Dimensions
D - Overall Width:
130" (3,302 mm)
E - Outside Length:
243" (6,172 mm)
F - Overall Length:
272" (6,908 mm)
G - Height of Columns:
104" (2,643 mm)
Inside Dimensions
H - Width Between Columns:
120" (3,048 mm)
I - Drive-Thru Clearance:
80.75" (2,052 mm)
Runways
J - Runway Width:
20" (508 mm)
K - Length of Runways:
227.5" (5,778 mm)
L - Width Between Runways:
34.5" (876 mm) or 41.5" (1,054 mm)
M - Runway Centerline:
57.5" (1,461 mm) or 64.5" (1,638 mm)
N - Outside Edge of Runways:
77.5" (1,969 mm) or 84.5" (2,146 mm)
Minimum Wheelbase
Rated Capacity:
160" (4,064 mm)
75% Capacity:
140" (3,556 mm)
50% Capacity:
115" (2,921 mm)
25% Capacity:
95" (2,413 mm
Locking
Locking Positions:
18
Lock Spacing:
Every 4" (102 mm)
Power Unit
Motor:
220 VAC / 60 Hz / 1 Ph
Noise:
45 dB
Shipping
Weight:
2,740 lbs. (1,242 kg)
Dimensions:
239" x 22" x 29" (6,070 mm x 558 mm x 737 mm)
Specifications
Capacity 14000
Design Four-Post
Type Closed-Front
Colors Gray
Country of Origin Asia
Service Type General
Mount Surface
Ramps Standard
