Autel MC40AP6I : MaxiCharger Home 40A EV Charger With In-Body Holster - NEMA 6-50

Product Description

Key Product Features:

• Manufacturer part number: MC40AP6I.
• Manufacturer model number: MAXI US AC W10-N6-H.
• MaxiCharger Home Level 2 residential EV charging station.
• Maximum output current: 40A.
• Adjustable charging output from 6A to 40A through the mobile app.
• Maximum charging power: 9.6kW at 240V.
• Input and output voltage: 208V ±15% or 240V ±15%.
• Frequency: 60 Hz.
• NEMA 6-50 plug-in power connection.
• SAE J1772 charging connector.
• 25-foot charging cable.
• Integrated in-body holster keeps the charging connector securely stored.
• Compatible with EVs and plug-in hybrid vehicles equipped with an SAE J1772 inlet.
• Tesla vehicles may be charged with a compatible J1772 adapter, sold separately.
• Autel Charge mobile app support.
• Remote charging start and stop.
• Charging-session monitoring.
• Scheduled charging helps users take advantage of preferred utility-rate periods.
• LED and mobile-app charging status indicators.
• Bluetooth connectivity.
• Wi-Fi connectivity.
• Ethernet connectivity.
• CAN and RS485 communication support for compatible energy-management equipment.
• OCPP 1.6J communication protocol.
• Designed for possible future upgrade to OCPP 2.0.1.
• App and AutoStart user-authentication options.
• Optional RFID card support.
• Over-the-air software updates.
• 20mA CCID ground-fault detection.
• Integrated overcurrent protection.
• Overvoltage and undervoltage protection.
• Built-in surge protection.
• Power-measurement accuracy rated at ±1% from 1% to full scale.
• NEMA 4 enclosure rating.
• Suitable for indoor or outdoor installation.
• Operating temperature range: -40°F to 131°F.
• Storage temperature range: -40°F to 185°F.
• Wall-mount installation.
• Compatible with an optional pedestal for floor mounting.
• Approximate dimensions: 13 × 7 × 3 inches.
• ENERGY STAR certified.
• OpenADR 2.0b certified.
• Complies with UL 2231-1, UL 2231-2 and UL 2594.
• Meets NEC Article 625 and CSA C22.2 requirements.
• FCC Part 15 Class B compliant.
• Manufacturer warranty: 36 months.
• Designed primarily for residential garages, carports and private parking areas.
