Capacity
Lifting Capacity*
40,000 lbs. (18,144 kg)
*Max Capacity / Front Axle
20,000 lbs. (9,072 kg)
*Max Capacity / Rear Axle
20,000 lbs. (9,072 kg)
Rise
A - Min. Runway Height:
9.5" (241 mm)
B - Max. Rise:
60" (1,524 mm)
C - Max. Lifting Height:
67" (1,702 mm)
Time to Full Rise:
75 seconds
Outside Dimensions
D - Overall Width:
153.5" (3,899 mm)
E - Outside Length:
317" (8,052 mm)
F - Overall Length:
373.75" (9,487 mm)
G - Height of Columns:
91.25" (2,318 mm)
Inside Dimensions
H - Width Between Columns:
133.5" (3,391 mm)
I - Drive-Thru Clearance:
109" (2,769 mm)
Runways
J - Runway Width:
28" (711 mm)
K - Length of Runways:
316" (8,026 mm)
L - Width Between Runways:
40.75" (1,038 mm)
M - Runway Centerline:
74" (1,880 mm)
N - Outside Edge of Runways:
102" (2,592 mm)
Minimum Wheelbase
Rated Capacity:
230" (5,842 mm)
75% Capacity:
195" (4,953 mm)
50% Capacity:
165" (4,191 mm)
25% Capacity:
130" (3,302 mm)
Locking
Locking Positions:
13
Lock Spacing:
Every 4" (100 mm)
Power Unit
Motor:
220 VAC / 60 Hz. 1Ph.
Noise:
45 dB
Shipping
Weight:
6,748-lbs. (3,060 kg)
Dimensions:
266'' x 33'' x 37'' (6,756 mm x 838 mm x 940 mm)
Specifications
Capacity 40000
Design Four-Post
Configuration Closed-Front
Type Heavy Duty
