Capacity
Lifting Capacity*
40,000 lbs. (18,144 kg)
*Max Capacity / Front Axle
20,000 lbs. (9,072 kg)
*Max Capacity / Rear Axle
20,000 lbs. (9,072 kg)
Rise
A - Min. Runway Height:
9.5" (241 mm)
B - Max. Rise:
60" (1,524 mm)
C - Max. Lifting Height:
69.5" (1,765 mm)
Time to Full Rise:
75 seconds
Outside Dimensions
D - Overall Width:
153.5" (3,899 mm)
E - Outside Length:
257" (6,528 mm)
F - Overall Length:
313.75" (7,969 mm)
G - Height of Columns:
91.25" (2,318 mm)
Inside Dimensions
H - Width Between Columns:
133.5" (3,391 mm)
I - Drive-Thru Clearance:
109" (2,769 mm)
Runways
J - Runway Width:
28" (711 mm)
K - Length of Runways:
255.5" (6,490 mm)
L - Width Between Runways:
40.75" (1,035 mm)
M - Runway Centerline:
74" (1,880 mm)
N - Outside Edge of Runways:
102" (2,591 mm)
Minimum Wheelbase
Rated Capacity:
185" (4,699 mm)
75% Capacity:
160" (4,064 mm)
50% Capacity:
135" (3,429 mm)
25% Capacity:
110" (2,794 mm)
Locking
Locking Positions:
13
Lock Spacing:
Every 4" / 100 mm
Power Unit
Motor:
220 VAC / 60 Hz. 1Ph.
Noise:
45 dB
Shipping
Weight:
6,748-lbs. (3,060 kg)
Dimensions:Â
266'' x 33'' x 37'' (6,756 mm x 838 mm x 940 mm)
Specifications
Capacity 40000
Design Four-Post
Configuration Closed-Front
Type Heavy Duty
