Capacity
Lifting Capacity*
14,000 lbs. (6,350 kg)
*Max Capacity / Front Axle
7,000 lbs. (3,175 kg)
*Max Capacity / Rear Axle
7,000 lbs. (3,175 kg)
Rise
A - Min. Runway Height:
7.75" (197 mm)
B - Max. Rise:
70" (1,778 mm)
C - Max. Lifting Height:
77.5" (1,968 mm)
Time to Full Rise:
60 seconds
D - Overall width (FRONT)
143.25” (3,639 mm)
E - Overall Width (REAR)
130” (3,302 mm)
F - Outside Length
215.5" (5,474 mm)
G - Overall Length
244.5" (6,210 mm)
H - Height of Columns (FRONT)
103.25" (2,622 mm)
I - Height of Columns (REAR)
92” (2,337 mm)
J - Width Between Columns (FRONT)
123” (3,124 mm)
K - Width Between Columns (REAR)
120” (3,046 mm)
L - Drive-Thru Clearance
98” (2,489 mm)
M - Runway Width
20" (508 mm)
N - Length of Runways
197.5" (5,017 mm)
O - Width Between Runways
42" (1,067 mm)
P - Runway Centerline
65" (1,651 mm)
Q - Outside Edge of Runways
85" (2,159 mm)
Minimum Wheelbase
Rated Capacity:
140" (3,556 mm)
75% Capacity:
120" (3,048 mm)
50% Capacity:
100" (2,540 mm)
25% Capacity:
80" (2,032 mm)
Locking
Locking Positions:
15
Lock Spacing:
Every 4" (102 mm)
Power Unit
Motor:
220 VAC / 60 Hz / 1 Ph
Noise:
45 dB
Shipping
Weight:
3,238 lbs. (1,468.7 kg)
Dimensions:
221'' x 22'' x 35'' (5,613 mm x 558 mm x 889 mm)
Specifications
Capacity 14000
Design Four-Post
Configuration Open-Front
