General
| Material | Steel |
|---|---|
| Assembly Required | true |
| Portable | true |
| Assembled Weight Lbs | 66 |
Dimensions
| Height Overall Inches Rounded | 16.25 |
|---|---|
| Individual Frame Weight Pounds | 66 |
| Overall Width Max Inches Rounded | 10.5 |
Lifting Dimensions
| Lifting Height With 2 inch block Inches Rounded | 17 |
|---|---|
| Lifting Height With 3 inch block Inches Rounded | 17.75 |
| Lifting Height Stacked blocks Inches Rounded | 20 |
| Maximum Lift Point Spread Inches Rounded | 50.5 |
| Minimum Lift Point Spread Inches Rounded | 27 |
Lifting Capacity
| Lifting Capacity Pounds | 3500 |
|---|
Rise
| Time to Full Rise sec | 26 |
|---|
Locking Dimensions
| Locking Position Qty | 2 |
|---|
Runway Dimensions
| Width Between Runways Narrow/Standard Configuration Inches Rounded | 23.88 |
|---|
Power
| Horse power | 1 |
|---|---|
| Voltage | 110V 50/60HZ |
| Amps | 10 |
| Motor | 110V, 50/60Hz, 1PH |
| Noise dB | 70 |
| Watts | 1100 |
| Motor RPM | 3450 |
Clearance Dimensions
| Lowered Height Frame Only Inches Rounded | 2.38 |
|---|---|
| Lowered Height With 2 inch block Inches Rounded | 3.38 |
