Lifting Capacity : 12,000lbs (5500kg)
Lifting Time : 50s
Lifting Height : 72.4"-78.4"
Lowered Adapter Height : 4.5"
Drive-thru Clearance : 109.8"
Floor to Overhead Switch : 140.9" / 155.9" / 167.9"
Overall Width : 157" (including pump motor)
Overall Width : 151" (outside baseplates)
Overall Height : 149.9" / 165.9" / 176.9"
Inside Column Width : 123.7"
Power Requirements : 220 / 1-Phase / 25amp
Gross Weight : 2600 lbs
Packing Dimensions : 116.8"x22.4"x30.5"
Accessory Box Dimensions : 32.25"x10.25"x12.5"
