Self-relieving diaphragm regulators for use in systems requiring up to a maximum of 200 scfm
Â
Supplies hydraulic oil to accumulators in oil rig blow-out prevention systems.
| Air Inlet Size (cm) | 1.27 |
|---|---|
| Air Inlet Size (in) | 1/2 |
| Air Inlet Size (mm) | 12.7 |
| For Use With | Senator, Bulldog, President, Glutton, Husky 2150 |
| Gauge Port Size (cm) | 0.635 |
| Gauge Port Size (in) | 1/4 |
| Gauge Port Size (mm) | 6.35 |
| Gauge Port Type | NPT |
| Handle Type | Tee |
| Includes | Regulator Only |
| Maximum Air Flow Rate (SCFM) | 200 |
| Maximum Air Inlet Pressure (bar) | 21 |
| Maximum Air Inlet Pressure (kPa) | 2100 |
| Maximum Air Inlet Pressure (psi) | 300 |
| Maximum Operating Temperature (°C) | 49 |
| Maximum Operating Temperature (°F) | 120 |
| Maximum Regulated Pressure (bar) | 8.6 |
| Maximum Regulated Pressure (kPa) | 860 |
| Maximum Regulated Pressure (psi) | 125 |
| Minimum Operating Temperature (°C) | 4 |
| Minimum Operating Temperature (°F) | 40 |
| Minimum Regulated Pressure (bar) | 0 |
| Minimum Regulated Pressure (kPa) | 0 |
| Minimum Regulated Pressure (psi) | 0 |
| Maximum Air Inlet Pressure (MPa) | 2.1 |
| Maximum Regulated Pressure (MPa) | 0.86 |
| Air Outlet Size (cm) | 1.27 |
| Air Outlet Size (in) | 1/2 |
| Air Outlet Size (mm) | 12.7 |
| Air Outlet Thread Type | NPT |
Specifications
Type Accessories
