| Maximum Regulated Pressure (kPa) | 1100 |
|---|---|
| Maximum Regulated Pressure (MPa) | 1.1 |
| Maximum Regulated Pressure (psi) | 180 |
| Minimum Operating Temperature (°C) | 4 |
| Maximum Regulated Pressure (bar) | 11 |
| Maximum Operating Temperature (°F) | 120 |
| Maximum Operating Temperature (°C) | 49 |
| Maximum Air Inlet Pressure (psi) | 300 |
| Maximum Air Inlet Pressure (MPa) | 2.1 |
| Maximum Air Inlet Pressure (kPa) | 2100 |
| Maximum Air Inlet Pressure (bar) | 21 |
| Includes | Regulator Only |
| Handle Type | Knob |
| Gauge Port Type | NPT |
| Gauge Port Size (mm) | 3.175 |
| Gauge Port Size (in) | 1/8 |
| Gauge Port Size (cm) | 0.3175 |
| For Use With | Mini-Flo, Standard, Fast-Ball |
| Air Inlet Thread Gender | Female |
| Air Inlet Size (mm) | 6.35 |
| Air Inlet Size (in) | 1/4 |
| Air Inlet Size (cm) | 0.635 |
| Minimum Operating Temperature (°F) | 40 |
| Minimum Regulated Pressure (bar) | 0 |
| Minimum Regulated Pressure (kPa) | 0 |
| Minimum Regulated Pressure (psi) | 0 |
| Outlet Size (cm) | 0.635 |
| Maximum Air Flow Rate (SCFM) | 15 |
| Outlet Size (in) | 1/4 |
| Outlet Size (mm) | 6.35 |
| Outlet Thread Gender | Female |
GRACO 110318 : Air Regulator - 1/4" NPT(F) - 0-180 PSI
Graco
$55.75
