Overall height:
78" (1,981 mm)
Inside height:
54" (1,372 mm)
Inside width:
32" (813 mm)
Turntable diameter:
30" (762 mm)
Tank capacity:
53 gallons
Load capacity:
1,000 lbs. (454 kg)
Cycle timer:
0 - 60 minutes
Recommended floor space:
44" x 43" (1,118 mm x 1,092 mm)
Brass Nozzles:
22
Steel construction:
12 Gauge / .109 thickness
Pump output:
70 psi @ 70 gpm
Motor:
3 HP / 380-415V / 50 Hz / 3 Ph
Electric heater:
6 kW
Water temperature:
160° - 180° F (71° - 82° C)
Shipping weight:
704 lbs. (319 kg)
Shipping dimensions:
46'' x 46'' x 80'' (1,168 mm x 1,168 mm x 2,032 mm)
Specifications
Power 380-415V
Phase 3-Ph
Frequency 50hz
