Overall Length
with Extension and Ramp
with Extension and Ramp
141.8 in. / 3,603 mm
Overall Length
with Ramp, No Extension
with Ramp, No Extension
123.75 in. / 3,142 mm
Overall Width
with Side Extension Decks
with Side Extension Decks
53.3 in. / 1,354 mm
Overall Width
No Side Extension Decks
No Side Extension Decks
31.9 in. / 810 mm
Lowered Height
7.5 in. / 188 mm
Full Rise - Top Deck
45.3 in. / 1,153 mm
Top of Stand Poles at Full Rise
108 in. / 2,740 mm
Top Deck – 1st Lock Position
24.5 in. / 625 mm
Top Deck – 6th Lock Position
7.75" (197 mm)
Lifting Capacity
1,500 lbs. / 680 kg
Air Supply
40 to 120 psi at 98 to105 in/3
Power Supply / Pump
Compressed Air / Hydraulic
Shipping Weight
808 lbs. (367 kg)
Shipping Dimensions
46'' x 91'' x 16'' (1,168 mm x 2,311 mm x 406 mm)
Specifications
Style Extended
