Compressor Flow Rate:
1/3 HP / 12 cc
Vacuum Pump:
70 L/min / 0.05 mbar / Dual Stage
Filter Drier:
710 cc / Double
Tank Capacity:
50 lbs. (23 kg)
Hose Length:
9’ (2.75 m)
Manometers:
3.5" (80 mm) Pulse-free Class 1
Tank Manometers:
1.5" (38 mm)
HP & LP Pressure Transducers:
No
Pump Oil:
50H
Display:
4" x 1.5" (102 mm x 38 mm) LCD
Front Wheels:
4" (102 mm) Casters w/ Locks
Rear Wheels:
12" (305 mm) Rubber Tread
Unit Height:
38" (965 mm)
Unit Width:
18" (457 mm)
Unit Depth:
30" (762 mm)
Unit Weight:
221 lbs. (100 kg)
Operating Temperature:
41°F to 104°F, 5°C to 40°C
Languages:
English, French, Spanish, Chinese
Voltage:
110 VAC / 60 Hz
Shipping Weight
276 lbs. (125 kg)
Shipping Dimensions
20'' x 32'' x 44'' (558 mm x 812 mm x 1,117 mm)
