Holding Capacity, Each
1,500 lbs. (680 kg)
Load Rating: 4 Dollies
6,000 lbs. (2,722 kg) Max.
Tire Width Max.
11 in. (279.4 mm)
Tire Diameter Range
15 in. – 34 in. (381 mm – 864 mm)
Stowed Dimension
24 in. (L) x 24.5 in. (W) x 8.5 in. (H) (610 mm (L) x 622 mm (W) x 216 mm (H))
Frame Length
24 in. (610 mm)
Frame Width, w/o Casters
23 in. (584 mm)
Caster Diam. X Width
4 in. x 1.25 in. (102 mm x 32 mm)
Min. – Max. Roller Spread Adjustment
9.5 in. - 25.5 in. (241 mm - 648 mm)
Roller Width
11 in. (279.4 mm)
Roller Diameter
3 in. (76 mm)
