Lifting Capacity
6,000 lbs. (2,722 kg)
A - Lowered Height (with 2" block)
3.5" (89 mm)
B - Lifting Height (with 2" block)
21" (521 mm)
C - Lifting Height (with 3" block)
22" (546 mm)
D - Max. Lift Height
24" (616 mm)
E - Lift Height (with adapters)
24" (597 mm)
F - Lift Height (with adapters + pin)
26.75" (673 mm)
G - Max. Lift Point Spread
60" (1,524 mm)
H - Min. Lift Point Spread
37" (940 mm)
I - Frame Width (each)
11" (278 mm)
J - Frame Length (each)
70" (1,778 mm)
Frame Weight (each)
78 lbs. (35 kg)
Time to Full Rise
30 seconds
Power Unit Weight
15 lbs. (7 kg)
Shipping Dimensions (each frame)
73.5" (L) x 15.25" (W) x 5" (H)
(1,869 mm x 385 mm x 129 mm)
(1,869 mm x 385 mm x 129 mm)
Shipping Weight
240 lbs. (109 kg)
Specifications
Capacity 6000
Power 208-240V
Type Portable Car Lift
Phase 1PH
Frequency 50/60 HZ
