Lifting Capacity
10,000 lbs. (4,536 kg)
Max. Capacity / Front Axle
5,000 lbs. (2,268 kg)
Max. Capacity / Rear Axle
5,000 lbs. (2,268 kg)
A - Height Overall
148" (3,759 mm)
B - Width Overall (at Baseplate)
137.5" (3,492 mm)
C - Width Outside of Columns
128.5" (3,264 mm)
D - Floor to Overhead Switch Bar
142.5" (3,619 mm)
E - Width Inside Columns
114.5" (2,908 mm)
F - Front Arm Reach (Min.)
22.5" (571 mm)
F - Front Arm Reach (Max.)
43.25" (1,099 mm)
G - Rear Arm Reach (Min.)
33.5" (845 mm)
G - Rear Arm Reach (Max.)
53.25" (1,353 mm)
H - Min. Pad Height
3.9" (100 mm)
I - Rise
70" (1,778 mm)
J - Max. Lift Height (Pad + 63mm Adapt.)
76.5" - 78.5" (1,943 - 1,994 mm)
K - Drive-Thru Clearance
103" (2,618 mm)
Screw Pad Adjustment
2" (51 mm)
Motor
220 VAC / 60Hz / 1 Ph
Time of Full Rise
65 seconds
Max. Load Per Arm
2,500 lbs. (1,134 kg)
Shipping Weight
1,545 lbs. (703 kg)
Specifications
Capacity 10000
Power 220V
Type 2-Post Lift
Style Clearfloor
Phase 1Ph
