Rotary 091900 : Air Jack

Product Description

Key Product Features:

• 2-ton lifting capacity: Provides up to 4,000 pounds of lifting support for compatible vehicle body, frame, and collision-repair applications.
• Pneumatic three-bag design: Uses a three-bag air-jack configuration to deliver controlled vertical lifting without a conventional hydraulic pumping mechanism.
• Simple raise-and-lower controls: Clearly marked green and red arrow controls make operation quick and intuitive for body-shop technicians.
• Load-holding air valves: The valve system is designed to maintain the jack’s position when the compressed-air line is disconnected.
• Shared airline capability: Because the jack can hold its position without a continuous air connection, the same airline can be disconnected and used with other pneumatic shop tools.
• 5.75-inch closed height: The low-profile collapsed height helps technicians position the jack beneath compatible vehicle structures and lifting points.
• 13.75-inch extended height: Provides approximately 8 inches of vertical travel between the fully lowered and fully raised positions.
• Compact lifting solution: Its relatively low collapsed profile and pneumatic construction make it useful where larger floor jacks may be difficult to position.
• Designed for body repair pulling systems: Intended for collision-repair environments where vehicles must be raised or repositioned during frame straightening and structural repair.
• Supports vehicle body alignment: Helps technicians position vehicle sections and create working clearance during body and frame repair procedures.
• Improves repair efficiency: Fast pneumatic operation reduces the manual effort associated with conventional mechanical or hydraulic jacking methods.
• Position-retention safety feature: The load-holding valve design helps reduce the chance of unexpected jack movement caused by removing the airline.
• Male air coupler fitting: The jack is equipped with a male pneumatic fitting for connection to a compatible compressed-air supply.
• No separate mounting hardware included: The product is supplied as an air jack and does not include mounting hardware, according to available specifications.
• Optional Saddle-Mate compatibility: Chief identifies the Saddle-Mate as a useful accessory that fits on top of the air jack and distributes the lifting load across a larger portion of the sill or pinch weld.
• Professional collision-repair applications: Suitable for collision centers, automotive body shops, frame-straightening facilities, dealership body departments, vocational training centers, and fleet repair operations.
• Part number 091900: Listed under Rotary and Chief Automotive Technologies as part number 091900, with some approved-equipment programs identifying it as CAS091900.

Why Buy from ProQuip Solutions:

Purchase the Rotary 091900 Air Jack from ProQuip Solutions for a fast, compact, and dependable pneumatic lifting solution for professional collision-repair work. Its 2-ton capacity, low collapsed height, simple push-button operation, and position-holding valve design make it a practical accessory for vehicle pulling systems and body-alignment procedures.

ProQuip Solutions can also assist with compatible collision-repair systems, air fittings, lifting accessories, Saddle-Mate supports, frame-rack equipment, replacement components, and other professional body-shop tools.
