- Dual 100-Foot Hose Reels: Includes two hose reels, each designed to accommodate up to 100 feet of compatible high-pressure hose for convenient storage and organization.
- Heavy-Duty Mild Steel Construction: Features a durable mild steel frame designed to support professional pressure washing equipment.
- HD Pallet Skid Configuration: Provides a dedicated skid-style mounting platform for commercial pressure washer applications.
- Karcher HD Series Gas Skid Family: Part of Kärcher's professional HD Series Gas Skid accessory range.
- Cold Water Gas Pressure Washer Applications: Intended for compatible gas-powered cold water pressure washing equipment and professionally configured mobile cleaning systems.
- Dual Hose Storage Capability: The two-reel arrangement provides separate storage locations for compatible pressure washer hoses.
- Extended Hose Storage: Each reel offers a manufacturer-listed 100-foot capacity, supporting hose management for larger cleaning areas.
- UTV and ATV Bed Applications: Designed to fit within suitable utility vehicle cargo beds, subject to actual bed dimensions and load capacity.
- Integrated Forklift Openings: Features forklift access openings for handling and positioning with appropriately rated equipment.
- Skid Feet Included: Kärcher identifies skid feet as included components in the HD Series Gas Skid range.
- Mobile Pressure Washing Applications: Provides a practical equipment platform for suitable trailers, utility vehicles, and mobile cleaning arrangements.
- Convenient Hose Management: Helps keep pressure washer hoses organized during equipment storage, transportation, and cleaning preparation.
- Reduced Hose Clutter: The integrated reels help minimize loose hoses around the pressure washer and work area.
- Commercial Cleaning Applications: Suitable for properly configured systems used in fleet washing, commercial property maintenance, and equipment cleaning.
- Industrial Equipment Washing: Supports mobile pressure washing setups used for construction equipment, agricultural machinery, and industrial maintenance.
- Pressure Washer Equipment Integration: Designed to accommodate appropriate cleaning equipment mounting arrangements, subject to model-specific verification.
- Professional Hose Storage Solution: Offers an organized alternative to manually coiling pressure washer hoses around equipment frames.
- 172 lb Shipping Weight: Kärcher's current professional catalog specifies a shipping weight of approximately 172 pounds.
- 40 × 48 × 35-Inch Shipping Dimensions: The 2026 Kärcher Professional Catalog lists shipping dimensions of 40 inches long, 48 inches wide, and 35 inches high.
- Assembly Required: The HD Pallet Skid requires assembly and appropriate equipment mounting before operation.
- Pressure Washer Sold Separately: The skid does not include a gas-powered pressure washer.
- No Integrated Water Tank: Unlike the single-reel tank configuration, this dual-reel model does not include the 50-gallon water tank.
- Alternative Single-Reel Tank Configuration: Kärcher offers 9.807-833.0, featuring a 50-gallon water tank and one 100-foot-capacity hose reel.
- Optional Rubber Feet Kit: Kärcher lists 8.923-105.0 as an additional rubber feet accessory within the HD Series Gas Skid range.
- Optional Inlet Filter Kit: Part number 8.923-107.0 is separately listed for compatible equipment configurations.
- Optional Lifting Eye Bolts: Kärcher identifies 8.923-106.0 as an optional lifting eye bolts kit for supported installations.
- Optional Three-Way Valve Kit: Kärcher lists 8.923-108.0 as a separate accessory for compatible water supply arrangements.
- Professional Equipment Organization: Combines equipment mounting provisions and dual hose reel storage into a single skid assembly.
- Manufacturer Part Number Identification: Identified as Karcher 9.807-838.0 for accurate product selection and ordering.
The Karcher 9.807-838.0 is an HD Pallet Skid with Two Hose Reels, not a complete pressure washer.
The manufacturer confirms the following:
| Attribute | Manufacturer-listed detail |
|---|---|
| Product | HD Pallet Skid with 2 Hose Reels |
| Part Number | 9.807-838.0 |
| Frame Material | Mild steel |
| Hose Reels | 2 |
| Hose Reel Capacity | 100 ft each |
| Water Tank | Not included |
| Shipping Weight | 172 lb |
| Shipping Dimensions | 40 × 48 × 35 inches (2026 catalog) |
| Assembly | Required |
| Pressure Washer | Sold separately |
Pressure Washer Compatibility: Although this skid belongs to the HD Series Gas Skid family, Kärcher's technical data does not specify individual compatible pressure washer models for part number 9.807-838.0. Confirm the intended equipment's frame and mounting compatibility before ordering.
Hose Inclusion Note: Two hose reels are included, but the manufacturer documentation does not confirm that high-pressure hoses are supplied. The 100-foot designation refers to each reel's storage capacity.
Dimension Verification: Kärcher's 2026 catalog lists shipping dimensions of 40 × 48 × 35 inches, while an earlier manufacturer brochure lists 47 × 40 × 35 inches. Confirm current shipping dimensions before arranging transportation.
Installation and Safety Note: Confirm equipment mounting points, skid load capacity, vehicle payload limits, and required hose connections before installation. Secure the assembled skid appropriately during transportation and operation.
