Lifting Capacity
4,500 lbs. / 2,041 kg
Maximum Rise
77.75 in. / 1,972 mm
Overall length
91.25 in. / 2,318 mm
Top Deck length (with handles)
71.25 in. / 1,807 mm
Top Deck Length
63 in. / 1,600 mm
Overall Width (with handles)
53 in / 1,348 mm
Top Deck Width
42.75 in. / 1,088 mm
Screw Jack Max. Adjustment
1.5 in. / 38 mm
Minimum Deck Height
34.25 in. / 868 mm
Height of Steering Handle
39.25 in. / 997 mm
Motor
12VDC
Operating Pressure at Max Load
1720 psi
Battery Charger
Input: 120 VAC, 60 Hz. / Output: 12VDC, 15A
Battery Charge Time
10-12 Hours to full charge from ≈20%
Lifting Time
≈18 seconds
Weight
1,918 lbs. / 870 kg
Specifications
Capacity 3000
Design Scissor
Lift Accessory Efficiency
Lift Type Bridge Jack, Scissor
Style Extended
Type General Svc, Motocycle, Motorcycle Jack
