Flo-Dynamics 40400050 : DFPSX-500 Differential & Power Steering Fluid Exchanger

Product Description

Key Product Features:

• Two independent service systems: Combines dedicated differential and power steering fluid service functions within one mobile unit.
• Multiple driveline applications: Supports fluid draining and refilling on differentials, manual transmissions, transfer cases, and compatible gearboxes.
• Power steering fluid exchange capability: Drains used fluid and supplies clean replacement fluid through the vehicle’s power steering reservoir.
• Two high-volume differential pumps: Uses two gear pumps rated at approximately 4 GPM to move thicker differential and driveline lubricants efficiently.
• Designed for heavy gear oils: Gear-pump construction is suited to the thicker, heavier fluids commonly found in differentials, manual transmissions, and transfer cases.
• Two power steering diaphragm pumps: Dedicated pumps rated at approximately 0.9 GPM each support simultaneous removal and replacement of power steering fluid.
• Fast power steering service: Capable of replacing up to 95% of the old power steering fluid in less than eight minutes under suitable service conditions.
• Dual drain-and-fill operation: Separate power steering service hoses remove used fluid and introduce clean fluid through the system reservoir.
• Clear power steering hoses: Transparent hoses allow the technician to observe clean and used fluid movement during the exchange.
• Independent fluid controls: Separate new-fluid and waste-fluid switches give the operator direct control over the power steering exchange process.
• Fingertip-controlled pendant: An operating pendant with approximately 11 feet of reach allows the technician to control the machine while positioned near the service point.
• Simple two-button driveline operation: Straightforward controls make differential draining and refilling easier to manage.
• Flexible driveline adapters included: Supplied with flexible adapters designed to access a variety of differential, transmission, and transfer-case fill or drain openings.
• Multiple suction-wand sizes: The quick-start procedure directs technicians to select an appropriate adapter and use the larger suction wand whenever the application permits.
• Adapter storage rack: Integrated storage keeps the included driveline adapters organized and readily accessible.
• Serviceable magnetic filter: Captures metal particles removed from driveline components and can be serviced as part of routine machine maintenance.
• Direct bottle connection: The clean-fluid system connects to commercially available 64-fluid-ounce bottles, helping technicians switch between fluid types without contaminating a shared permanent tank.
• Reduced cross-contamination risk: Bottle-fed operation is useful for shops handling multiple gear-oil viscosities and power steering fluid specifications.
• One-gallon waste bottle: Used fluid is collected in a dedicated 1-gallon container for convenient handling and disposal.
• 12V DC operation: Connects directly to the serviced vehicle’s battery, eliminating the need for a nearby AC power outlet.
• Portable service capability: Vehicle-powered operation allows the machine to perform fluid services throughout the workshop or in locations without convenient shop-air or AC access.
• Mobile roll-around cabinet: The compact wheeled design makes the unit easy to position beside a vehicle lift or move between service bays.
• Organized upper storage area: Recessed storage areas help keep adapters and commonly used service tools close to the machine.
• Separate fluid pathways: The dedicated differential and power steering systems support efficient multi-fluid servicing from a single machine.
• Professional-grade construction: Designed for operation by trained automotive technicians in demanding commercial service environments.
• Machine dimensions: Approximately 38 inches high × 18 inches wide × 25 inches deep.
• Current listed weight: The manufacturer’s current product page lists the machine at approximately 88 lbs. An older promotional flyer lists a lower weight, so the current product-page specification should be used for ordering and shipping purposes.
• One-year limited warranty: Flo-Dynamics warrants the equipment to the original purchaser against qualifying defects in materials and workmanship for one year from the original invoice date.
• Manufacturer part number: 40400050.
• Professional applications: Ideal for automotive dealerships, independent repair shops, differential specialists, transmission facilities, fleet maintenance departments, quick-lube centers, and vocational automotive programs.

Why Buy from ProQuip Solutions:

Purchase the Flo-Dynamics 40400050 DFPSX-500 Differential and Power Steering Fluid Exchanger from ProQuip Solutions for a versatile two-in-one machine that expands your shop’s driveline and steering-fluid service capabilities. ProQuip Solutions can assist with compatible adapters, replacement bottles, hoses, filters, pumps, fittings, and maintenance components, helping your technicians perform cleaner and more efficient differential, transfer-case, manual-transmission, and power steering services.
