Specifications
- Rim diameter from: 13” to 32”
- Maximum tire diameter: 47,2” (1200 mm)
- Clamping: automatic
- Drive system: 2-speed inverter motor
- Torque: 885 ft/lb (1200 Nm)
- Rotational speed: 7-20 rpm
- Maximum bead breaking range: 19”
- Upper/Lower bead breaker force: 1641,1 lbf (7300 N)
- Wheel lifter load capacity: 187 lb (85 Kg)
- Power supply: 1Ph 230V-0.98 kW 50Hz/60 Hz
- Pneumatic operating pressure: 116 to 145 psi (8 to 10 bar)
- Weight: 1311,8 lb (595 Kg)
