Specifications
Operation | Lay back, center mount |
Wheel Handled | Budd & Dayton Tubeless |
Mount Demount | Center Post |
Tool head Offset | Independent removable, mount in table |
Table | Lay back |
Wheel Clamping Method | Lay back, center mount |
Wheel Lift | Tilt back |
Frame Structure | Tilt Table |
Max. Tire Diameter | 44” |
Max. Tire Width | 16” |
Rim Diameter Range | 16.5"-24.5" |
Electric Specifications | 220v / 1ph or 220v / 3ph, 60Hz |
Air Required | Yes |
Max. Chuck Torque | 2900 ft/lbs |
Max. Overall Dimension | 78”(w) x 48”(d) |
Weight with Standard Accessories (shipping) | 1150 lbs |
