Specifications
Wheels Handled | Alloy and Steel for Car and Light Truck |
Rim Diameter | 12" - 30" |
Maximum Tire Diameter | 50" Max |
Maximum Rim Width | 15" Max |
Bead Loosening System | Hand Control - Power In/Out and Freeze |
Wheel Clamping System | Center Clamp with Manual Lock |
Mount/Demount Mechanism | Leverless Duckhead® Mount/Demount Tool - no tire bar necessary |
Helper Devices | Robo-Arm® (18" of Automated Vertical Stroke) RoboRoller® |
Bead Seating Air Volume | 5.4 Gallons in Tower |
Inflation Gauge | 0 - 60 psi |
Air Supply Gauge | 0 - 300 psi |
Air Drive System | 1.5 HP Air Motor, 110 - 175 psi, 15 scfm (Air Model Only) |
Electric Drive System | 2 HP Electric Motor, 220V, 60 Hz, 14amp (Electric Models Only) |
Footprint | 74"w x 88"h x 65"d |
Ship Weight | 700 lbs. |
