| Capacity | 12,000 lbs. |
| Rise | 75 3/4” – 78 1/8” |
| Overall Height | Standard 13′ 8″ | Low 11' 8" |
| Base Required Ceiling Height | 102 3/8" |
| Drive-Thru | 8′ 6 3/8″ |
| Inside Columns | 114 7/8" |
| Arm Reach Min/Max | 27 3/8" / 59 1/8" |
| Min. Adapter Height | 4 5/8″ |
| Min. Bay Size | 12’x26′ |
| Min. Ceiling Height | Standard 13' 9" | Standard 11' 10 3/4" |
| Motor / Voltage 1Ø | 2 HP / 208-230V |
| Time of Full Rise | 60 secs. |
Videos Hide Videos Show Videos
Specifications
Capacity 12000
Design Two-Post
Configuration Symmetric
Overall Height 200''
Overall Width 138''
Inside Columns 114''
Colors Red
Colors Blue
Country of Origin USA
Size 3' Height Ext.
Arms / Adapters All Vehicle
Shockwave No
