Specifications
Max. Wheel Width 71’’ | 1800mm
Max. Wheel Diameter 118’’ | 3000mm
Clamp Capacity 14’’ – 50’’
Wheel Center Hole Minimum 4.3’’ – 110mm
Hydraulic Power Unit Motor 3ph – 4,8kW
3-Speed Gear Motor Idraulico – Hydraulic 4 -6 -10 rpm
Max. Torque Delivery 5500Nm
Bead Breaker Force 4500N
Max. Wheel Weight 6,613lbs – 3000kg
Voltage 200 – 208 – 230 – 400 V – 3ph – 50/60Hz
Machine Weight 4,850lbs – 2200kg
Specifications
Type Heavy Duty
Clamping Chuck-Clamp
Power Electric
