Specifications
• Wheel Diameter : 12”- 32” (305 ÷ 660 mm)• Maximum Tire Diameter : 47.2” (1100 mm) (*)
• Maximum Tire Width :15” (360 mm)
• Tire Types : Conventional, low profile and Run Flat
• Clamping : Manual
• Drive System : 2 speed
• Rotation Torque : 811.8 ft/lb (1100 Nm)
• Rotation Speed : 7 - 18 rpm
• Maximum Bead Breaking Range : 18” (457 mm)
• Bead Breaking Force : 1710 lbs. (7600 N)
• Wheel Loading : Pneumatic
• Maximum Wheel Weight : 187.4 lb (85 Kg)
• Power Requirements : 110 Volt - 1,31 hp 50 Hz / 110V
• Packaging (L x D x H) : 48.8” x 59” x 72.4” (1240 x 1500 x 1840 mm)
• Shipping Weight : 883 Lbs.
