Specifications
Turntable
Inside clamping capacity - 13” - 29”
Outside clamping capacity - 10” - 26”
Maximum tire diameter - 1200 mm (47")
Maximum tire width - 14"
Rotation torque - 1200 Nm
Rotation speed - 6-15 rpm
Height of the plate above the ground - 715 mm
Bead breaker
Type - showel wheel on the ground
Maximum opening - min 40 - max 420 mm
Shoe force - 2756 lbs
Support - fixed rubber pad
Tool
Working range - 8-29"
Column - manual opening
Head - clamping manual
Power supply
Electrical - 1ph 115/1/60 Hz MI 2V
Pneumatic - on request
Operating pressure - 10 bar / 145 psi
Weight - 540 lbs
Dimensions L x D x H - Min. 38,5-Max 55" x 44" x 79"
Specifications
Type Swing-Arm
Clamping Rim-Clamp
Power Electric
