Specifications
Operation | 3 Jaw Chuck |
Wheel Handled | Budd & Dayton, Tube & Tubeless |
Mount Demount | Independent Hook & Roller |
Tool head Offset | Independent removable, mount in table |
Table | Moving table centered in frame |
Wheel Clamping Method | 3 Jaw Chuck |
Wheel Lift | Clamp Arm Lifting |
Frame Structure | Center Carriage |
Max. Tire Diameter | 76" |
Max. Tire Width | 25"+ |
Rim Diameter Range | 15"-44" |
Electric Specifications | 220v / 1ph or 220v / 3ph, 60Hz |
Air Required | No |
Max. Chuck Torque | 4400 ft/lbs |
Max. Overall Dimension | 96”(w)x108”(d)x66”(h) |
Weight with Standard Accessories (shipping) | 1600 lbs |
